1.1L Oil Capacity Gasoline Powered Engine 177F 9.0HP Engine Assembly

China FUAN GENFOR POWER EQUIPMENT CO., LTD. certification
I'm Online Chat Now

1.1L Oil Capacity Gasoline Powered Engine 177F 9.0HP Engine Assembly

1.1L Oil Capacity Gasoline Powered Engine 177F 9.0HP Engine Assembly
1.1L Oil Capacity Gasoline Powered Engine 177F 9.0HP Engine Assembly 1.1L Oil Capacity Gasoline Powered Engine 177F 9.0HP Engine Assembly 1.1L Oil Capacity Gasoline Powered Engine 177F 9.0HP Engine Assembly 1.1L Oil Capacity Gasoline Powered Engine 177F 9.0HP Engine Assembly 1.1L Oil Capacity Gasoline Powered Engine 177F 9.0HP Engine Assembly

Large Image :  1.1L Oil Capacity Gasoline Powered Engine 177F 9.0HP Engine Assembly

Product Details:

Place of Origin: China
Brand Name: GENFOR
Certification: CE
Model Number: GF177F

Payment & Shipping Terms:

Minimum Order Quantity: Sample accept
Price: Negotiable
Packaging Details: Carton/box
Delivery Time: 20-25days
Payment Terms: L/C, T/T
Supply Ability: 5000pcs/month
Detailed Product Description
Max.Power: 9.0HP Speed: 3000/3600RPM
Fuel: Gasoline Shaft: As Request
Start System: Hand Start Oil Capacity: 1.1L
Certification: CE,EPA,ISO Stroke: 4-Stroke
Cylinder: Sinle-Cylinder Displacement(cc): 270cc
High Light:

small gasoline engines

,

4 stroke gasoline engine

1.1L Oil Capacity Gasoline Powered Engine 177F 9.0HP Engine Assembly



Quality & Inspection



· Cooperated with good reputaiton suppliers.

· 100% check spare parts quality which produced from matching suppliers.

· QC checking each step from spare parts to production on the full of line.



1.1L Oil Capacity Gasoline Powered Engine 177F 9.0HP Engine Assembly 01.1L Oil Capacity Gasoline Powered Engine 177F 9.0HP Engine Assembly 1



Package



· Stardard exported color carton.

· We will use standard exported package if no special requirments, but it is available to provide colour package according to your design or we make design for you using your brand basing on the quantity more than 300pcs.



Technical Date



Model型号

GF154F

GF168F(E)

GF170F(E)

GF177F(E)

GF188F(E)

GF190F(E)

GF192F(E)

Engine Type

4-Stroke,Air-cooled,OHV Gasoline Engine 风冷,四冲程 OHV 引擎

Bore*Stroke(mm)

54*38

68*54

70*54

77*58

88*64

90*64

92*64

Displacement Capacity(cc)

87

196

208

270

389

420

440

Max.Output(HP)/rpm

2.4/3600

6.5/3600

7.0/3600

9.0/3600

13/3600

15/3600

16/3600

Max.Torque(N.m)

4.28/3600

10.11/3600

10.82/3600

14.39/3600

21.27/3600

26.5/3600

27.5/3600

Fuel Consumption(g/kWh)

393.2

417.1

422.2

360

353.9

346

343

Ignition System

Transistorized Magneto Ignition 晶体管点火

Fuel Tank Capacity(L)

1.6

3.6

3.6

6

6.5

6.5

6.5

Lubrication Oil

SAE 10W/30

Lubrication Oil Volume(L)

0.4

0.6

0.6

1.1

1.1

1.1

1.1

Starting System

Recoil

Recoil or Electric starter 手动或电动

Noise Level at 7m(dB)

72

80

80

86

90

92

92

Gross weight(kg)

11.5

18

18

27

33

36

37

Dimension(mm)

397*345*367

417*368*385

417*368*385

542*500*507

542*500*507

545*500*510

545*500*510

Per 20'GP CNT

594

528

528

176

176

172

172

per 40'GP CNT

1200

1068

1068

384

384

378

378
